The improved Tulip walkable ceiling is a flexible cleanroom ceiling system suitable for any classifications.
The hidden grid system and large module size minimize silicone lines and secure a fully air tight long life ceiling solution.
Improved inner profiles and connections create an excellent smooth surface and long life performance.
The Tulip Ceiling minimizes Gridlines above the ceiling to increase accessibility on top of ceiling.
Sandwich panel with integrated hanging profiles
Surface completely smooth and flush
Light fixtures flush integrated in the ceiling
Ceiling openings at any location, prefab in KCS factory
| Surface: | High resistant coated steel Various surface options available |
| Panel core: | Aluminum Honey comb Rockwool |
| Panel size: | Module: 1200x2400x60mm (WxHxT) Any size available |
| Load capacity: | 150 kg/m² Possible to increase load capacity |
| Pressure difference: | Minimum 150 PA Possible to increase pressure resistance |
| Fire resistance | Only non-combustible materials |
Other steel surfaces (stainless steel/VHP resistant) available
Reinforcement to increase load capacity
Pressed in opening for complete flush integration of lights and inletboxes
Service hatch with rubber seal flus built in
Sprinkler head fixing with cover in matching color
Bioled PRO lighting fixtures (LED) flush built in
Special cleanroom adoption of ceiling height differences
